Splice trays, adapter panels and pigtails are included

Item is not assembled and items are packaged separately

Recommended Items:
Fiber Jumpers	Distribution Fiber Cable	Fiber Cleaners

Pre-Loaded OM3 Multimode 10G LC 1U Fiber Enclosure/Patch Panel with Unjacketed Pigtails & Splice Trays

This rack mount fiber optic patch panel is a 1 Rack Unit (1U/1RU) high density FDU (Fiber Distribution Unit) that Includes OM3 Multimode 10G 12 Fiber none jacketed pigtails, LGX LC adapter panels and fiber splice trays. The fiber housing has a slide out master panel with an integrated tray stop to prevent over extension of fiber cables. The fiber enclosure also has a two-piece top and a front a rear door with latches to allow for easy access to the adapter panels. The FB36-6153R3 is one of a family of units that support fiber terminations in rack mount applications.

For additional fiber adapter panels use our LGX FB24 adapter panel inserts. To find out more, give us a call at ##STOREPHONE## or email us at ##STOREEMAIL##.

Pre-Loaded OM3 Multimode 10G LC 1U Fiber Enclosure/Patch Panel with Unjacketed Pigtails & Splice Trays Features:

Slide-Out FDU Patch Panel Enclosure Housing

Fits up to 72 fiber splices
Fits 3 LGX fiber optic adapter panels
Includes fiber splice trays
Durable powder coat finish
Made from SPCC steel
Smooth gliding pull out system
Two-piece easy access removable top
Tinted clear front door with metal rear door
Both front and rear doors have swell latches

Multimode OM3 10G Fiber Optic Unjacketed Pigtails, LC, 12 Strand Jacketed, 2 Meter

None jacketed Pigtail for tighter spaces.
Pre-terminated fiber to reduce installation time and ensure accuracy.
12 OM3 Multimode 10G LC connectors ready to plug directly into an adapter panel.

Fiber Adapter Plates

Steel LGX type adapter plates with black paint
LC duplex fiber adapters/couplers
Metal clips secure the adapters/couplers in the adapter plates

Loaded 1U Fiber Enclosure/Patch Panel with Splice Trays Specifications:

Included

Fiber Optic Enclosure/Patch Panel Housing

1U Steel Slide-Out Fiber Enclosure/Patch Panel

Pigtails

2 Meter 12 Fiber OM3 Multimode 10G Pre-Terminated LC Unjacketed Pigtail

Adapter Panels

LC LGX Fiber Adapter Panels
Blank LGX Adapter Plates

12-36 Fiber Splice Tray

1x 36 Fiber Splice Tray

48-72 Fiber Splice Trays

2x 36 Fiber Splice Trays

Physical Properties

Color

Black

Material

Powder Coated SPCC Steel

What's included

12 Fiber, LC OM3 Multimode 10G Fiber Enclosure/Patch Panel Contents

1 - Slide-Out 1U Fiber Patch Panel Enclosure Housing (FB36-6153R3)
1 - OM3 Multimode 10G 2 Meter 12 Fiber LC Unjacketed Pigtail
1 - 12 Port, LC OM3 Multimode 10G Duplex Adapter Panel
2 - Blank LGX Adapter Plates
1 - 36 Fiber Splice Trays

24 Fiber, LC OM3 Multimode 10G Fiber Enclosure/Patch Panel Contents

1 - Slide-Out 1U Fiber Patch Panel Enclosure Housing (FB36-6153R3)
2 - OM3 Multimode 10G 2 Meter 12 Fiber LC Unjacketed Pigtail
2 - 12 Port, LC OM3 Multimode 10G Duplex Adapter Panel
1 - Blank LGX Adapter Plates
1 - 36 Fiber Splice Trays

36 Fiber, LC OM3 Multimode 10G Fiber Enclosure/Patch Panel Contents

1 - Slide-Out 1U Fiber Patch Panel Enclosure Housing (FB36-6153R3)
3 - OM3 Multimode 10G 2 Meter 12 Fiber LC Unjacketed Pigtail
3 - 12 Port, LC OM3 Multimode 10G Duplex Adapter Panel
1 - 36 Fiber Splice Trays

48 Fiber, LC OM3 Multimode 10G Fiber Enclosure/Patch Panel Contents

1 - Slide-Out 1U Fiber Patch Panel Enclosure Housing (FB36-6153R3)
4 - OM3 Multimode 10G 2 Meter 12 Fiber LC Unjacketed Pigtail
2 - 24 Port, LC OM3 Multimode 10G Quad Adapter Panel
1 - Blank LGX Adapter Plates
2 - 36 Fiber Splice Trays

72 Fiber, LC OM3 Multimode 10G Fiber Enclosure/Patch Panel Contents

1 - Slide-Out 1U Fiber Patch Panel Enclosure Housing (FB36-6153R3)
6 - OM3 Multimode 10G 2 Meter 12 Fiber LC Unjacketed Pigtail
3 - 24 Port, LC OM3 Multimode 10G Quad Adapter Panel
2 - 36 Fiber Splice Trays
