Description

Oxygen Free Speaker Wire

18 Gauge

This 18 gauge speaker wire is composed of two bare copper conductors composed of 16 strands of copper per conductor. The copper conductors are made of oxygen free pure copper, lending it improved conductivity. It has a white PVC outer jacket and 18 gauge conductors. This speaker wire provides high quality audio signals from audio components to a receiver or amplifier. It is supplied in a pull box of 1,000 feet.

16 Gauge

This 16 gauge speaker wire is composed of 2 or 4 bare copper conductors composed of 65 strands of copper per conductor. The copper conductors are made of oxygen free pure copper, lending it improved conductivity. It has a white PVC outer jacket and 16 gauge conductors. This speaker wire is ideal for providing high quality audio signals from audio components to a receiver or amplifier. It is supplied in a pull box of 500 feet.

14 Gauge

Our 14 gauge speaker wire is composed of 2 or 4 bare copper conductors composed of 105 strands of copper per conductor. The copper conductors are made of oxygen free pure copper, lending it improved conductivity. With a white CMR rated outer jacket, this 14 gauge speaker wire is ideal for speakers, low voltage lighting and many other indoor or in-wall applications. Our 14 AWG speaker wire is also ETL listed. 14 gauge speaker wire provides high quality audio signals from audio components to a receiver or amplifier. It is supplied in a pull box of 500 feet.

Features

Features

18 Gauge Speaker Wire

Gauge: 18 AWG
# of conductors: 2
# of strands: 16
Shielding: N/A
# of feet on roll: 1000
Ratings: CMR
Jacket color: White
PVC Jacket
Pull Box

16 Gauge Speaker Wire

Gauge: 16 AWG
# of conductors: 2 or 4
# of strands: 65
Shielding: N/A
# of feet on roll: 500
Ratings: ETL, CMR
Jacket color: White
Sun resistant jacket
PVC Jacket
Pull Box

14 Gauge Speaker Wire

Gauge: 14 AWG
# of conductors: 2 or 4
# of strands: 105
Shielding: N/A
# of feet on roll: 500
Ratings: ETL, CMR
Jacket color: White
Sun resistant jacket
Pull Box

Specifications

18 AWG Speaker Wire Specs:			16 AWG Speaker Wire Specs:

	Conductor	Stranded Bare Copper		Conductor	OFC - Oxygen Free Copper
	Conductor Size	18 AWG		Conductor Size	16 AWG
	Number of Strands	16 Strands		Number of Strands	65 Strands
	Insulation Diameter	2.64mm		Insulation Diameter	N/A
	Insulation	PVC		Insulation	PVC
	Outer Jacket Diameter	5.64mm		Outer Jacket Diameter	N/A
	Jacket	White PVC		Jacket	White PVC
	Insulation Colors	1.Red 2.Black		Insulation Colors	1.Red 2.Black 3.White 4.Green
	Temperature	75°C		Temperature	75°C
	Center Resistance	21.20 (Ω/km)		Center Resistance	21.20 (Ω/km)

14 AWG Speaker Wire Specs:

	Conductor	OFC - Oxygen Free Copper
	Conductor Size	14 AWG
	Number of Strands	105 Strands
	Insulation Diameter	N/A
	Insulation	PVC
	Outer Jacket Diameter	N/A
	Jacket	White PVC
	Insulation Colors	1.Red 2.Black 3.White 4.Green
	Temperature	75°C
	Center Resistance	21.20 (Ω/km)

Additional Information

	Standards	UL \| CMR
	Important Notes	The information contained in this document is proprietary to CRN Solutions and may not be disclosed or transmitted to any other parties without the express written permission of CRN Solutions. This information is provided for the purposes of quotation only.

Additional Information

Additional Information :

To learn more about our Audio Bulk Cable here is a link to a page containing more information on our premium Audio Bulk Cable.
