Speaker Wire/ Audio Cable, 16/4 Oxygen Free CMX, Direct Burial, 500' White
16 AWG Speaker Wire
Our 16-gauge speaker wire features two bare copper conductors with 65 copper strands each, ensuring improved conductivity. Made of oxygen-free pure copper, it's enclosed in a black PVC outer jacket and meets UL and CL3 standards.
Ideal for delivering high-quality audio signals from audio components to a receiver or amplifier, this direct burial speaker wire is suitable for outdoor speakers and low-voltage lighting applications. Supplied on a wooden spool in a 500-foot length, its PVC jacket is sun-resistant and shields the conductors from water damage.
Features
Features
- Oxygen Free Copper (OFC)
- 16 AWG High Strand Count (65 strands)
- Direct Burial Sun Resistant PVC Jacket
- PVC Jacket Protects Against Water Damage
- UL Listed
- CMX Rated
- Meets CL3 Standards
Specifications
Specifications
| Specifications | 16 AWG Speaker Wire | 14 AWG Speaker Wire |
|---|---|---|
| Conductor | OFC - Oxygen-Free Copper | OFC - Oxygen-Free Copper |
| Conductor Size | 16 AWG | 14 AWG |
| Conductor Diameter | 65/0.16 | 105/0.16 |
| Insulation | 16 AWG | 14 AWG |
| Average Thickness | 0.31mm | 0.35mm |
| Insulation Diameter (™ 0.05mm) | 2.1mm | 2.6mm |
| Number of Strands | 65 | 105 |
| Insulation Colors | Red, Black, White, & Green | Red, Black, White, & Green |
| Outer Jacket | Direct Burial Sun Resistant PVC, CMX Rated | Direct Burial Sun Resistant PVC, CMX Rated |
| Outer Jacket Color | White & Black | White & Black |
| Average Thickness | 0.6 | 0.6 |
| Outside Diameter (™0.05mm) | 6.5 | 6.5 |
| Capacitance (Pf/m) | 65.2919 | 67.2605 |
| Nominal Velocity of Propagation VP(%) | 66 | 66 |
| Conductor DC Resistance DCR@20™C (ohm/km) | 13.124 | 8.2025 |
| Max. Operating Voltage-UL (Voltage) | 300 V RMS | 300 V RMS |
| Operating Temperature | -20˚C to 60˚C | -20˚C to 60˚C |
| Additional Information | |
|---|---|
| Standards | UL | CMX | CL3 |
| Important Notes | The information contained in this document is proprietary to CRN Solutions and may not be disclosed or transmitted to any other parties without the express written permission of CRN Solutions. This information is provided for quotation purposes only. |
Additional Information
Additional Information
Speaker Wire Accessories
Home theater speakers generally don™t come with speaker wire. This poses the challenge of determining the wire gauge and jacket type to suit the application. Primus Cable supplies premium-quality speaker wire with a CMX jacket rating, making it safe for floor-to-floor wiring. To ensure crystal clear home theater audio, be sure to invest in oxygen-free copper speaker wire from Primus Cable.
To learn more about our Speaker Wire Accessories please visit our overview page. Primus Cable Speaker Wire can be combined with a wide array of products such as:
- Audio/Video Keystone Jacks
- RCA Audio Cable
- RCA Splitter
- RCA Component Video Cable
- TV Ceiling and Wall Mounts
What's in the Box
What's In The Box
- Qty 1 - OFC Direct Burial Sun Resistant Jacket Audio Cable supplied on a 500 FT Wooden Spool
