Description

Our CAT 5E Shielded, Stranded Cable is ideal for your shielded indoor voice, data, video and security networking applications. Whether you are wiring your home, office or entire campus, we have the network solution that is right for you.

This CAT 5E Shielded Stranded Cable is CM Rated and the perfect fit for reliable installations where the cable will be used indoors. This cable's 8 conductors (4-Pairs) are stranded copper with a high density polyethylene (HDPE) insulation, over all foil shielding (FTP) and a PVC CM rated RoHS, RoHS2, & RoHS3 Compliant jacket. One common application for stranded cable is fabricating custom patch cables due to the flexibility that the stranded configuration offers. Our ETL Verified CM Rated Shielded Category 5E Stranded Cable is designed for indoor LAN applications, making it the ideal solution for indoor installation runs that require the cable to be installed in walls or any other non-plenum areas.

To make sure we are supplying our customer with high quality bulk Ethernet cables our cable have to meet and/or exceeds CAT 5E TIA 568 C.2 standards. Our CAT 5E shielded, stranded cable is also manufactured to meet current CAT 5E guidelines and is verified by outside standards organizations including ETL Verified as well as being RoHS, RoHS2, & RoHS3 Compliant.

Why Shielded Cable?

The foil shielding protects the signal from outside EMI’s and also keeps the signal from emitting its own EMI. For example, a hospital has many electronic devices that emit Electro Magnetic Interference so you would want to use a shielded cable to prevent EMI from both entering and exiting your cable.

Cat 5E Bulk Cable Options

Stranded Copper UTP	Stranded Copper F/UTP	Solid Copper UTP				Solid Copper F/UTP
General (CM)	General (CM)	General (CM)	Outdoor (CMX)	Riser (CMR)	Plenum (CMP)	Outdoor (CMX)	Riser (CMR)	Plenum (CMP)

Cat 6 Bulk Cable Options

Stranded Copper UTP	Stranded Copper F/UTP	Solid Copper UTP					Solid Copper F/UTP			Solid Copper S/FTP
General (CM)	General (CM)	General (CM)	Outdoor (CMX)	24AWG Riser (CMR)	23AWG Riser (CMR)	Plenum (CMP)	Outdoor (CMX)	Riser (CMR)	Plenum (CMP)	General (CM)

To avoid excessive shipping charges on 10 or more of this product please call 951-824-1571 or email support@primuscable.com to get a shipping quote.

Features

High-performance data communications cable for noisy environments
Suitable for 350MHz high speed data applications, Gigabit Ethernet, fast Ethernet and 155Mbps TP-PMD CDDI
Category-5E Foil Shielded Twisted Pair (F/UTP) Cable
4-pair, easily Identified Color-Striped Pairs
24 AWG Stranded Copper Conductors
Excellent attenuation and crosstalk characteristics
Sequential Foot Markers On Jacket
Exceeds EIA/TIA 568 B.2-1, CSA and ISO/IEC 11801 specifications
ETL Verified CM Rated
Supplied in 1000´ Pull Boxes
Designed for Indoor Installations
RoHS, RoHS2, & RoHS3 Compliant

Specifications

Additional Information

Solid Wire: also called solid-core or single-strand wire, consists of one piece of metal wire. Stranded wire is composed of a bundle of small-gauge wires to make a larger conductor and more flexible than solid wire. Solid wire is generally used for in-wall wiring where there is little need for flexibility in the wire.

CMR: The 'R' in CMR is for 'Riser'. Riser type cables are engineered to prevent the spread of fire from floor to floor and are suitable for vertical shaft applications.

CMP: The 'P' in CMP is for Plenum. Cables meeting type CMP requirements are suitable for installation in ducts and plenums without the use of conduit. These cables are designed for fire resistance and low-smoke and toxin producing characteristics.

CMX: The 'X' in CMX is for Outside Plant. Cables meeting type CMX requirements are suitable for installation in outdoor applications where exposed to the elements.

To learn more about our CAT5E Stranded CM Rated Ethernet Cable please visit our product overview page.

Solid Core Cable vs Stranded Cable

A solid core cable uses one solid wire per conductor and in a four pair cable there would be a total of eight solid wires. Stranded conductor uses multiple wires wrapped around each other in each conductor and in a four pair with seven strands per conductor cable, there would be a total of 56 wires.

Solid core cable is supposed to be used for permanently installed runs. It is less flexible than stranded cable and is more prone to failure if repeatedly flexed. Stranded cable is used for fly leads at the patch panel and for connections from wall-ports to end devices, as it resists cracking of the conductors. A stranded core is generally more expensive than a solid core.

Connectors need to be designed differently for solid cores than for stranded. Use of a connector with the wrong cable type is likely to lead to unreliable cabling. Plugs designed for solid and stranded cores are readily available, and we even offer plugs designed for use with both types.

Our CAT5E Stranded CM Rated Ethernet Cable is compatible with our:

What's in the Box?

Qty - 1000FT Pull Box of Shielded CAT5E Bulk Stranded Ethernet Cable
