Collection: LC Fiber Connectors

LC fiber connectors provide a compact, high-density termination solution for fiber optic networks. The LC uses a 1.25mm ferrule, half the size of the SC's 2.5mm ferrule, allowing double the port density in patch panels and enclosures. The push-pull design with locking tab provides secure mating while remaining easy to access in congested patch fields.

Field-Installable LC Connectors

Our field-installable LC connectors include Corning UniCam mechanical splice connectors with factory-polished end faces and ceramic ferrules. Tool-free installation terminates fiber in under a minute without consumables, making them ideal for quick field repairs and workstation drops. Jonard Sparc mechanical connectors offer a similar tool-free design supporting both 250µm and 900µm coated fiber. Available in single mode OS2 and multimode OM1, OM3, and OM4 with UPC or PC polish.

Fusion Splice-On LC Connectors

Corning FuseLite splice-on LC connectors provide fusion splice connectivity with splice protection built into the connector body. The factory-polished end face eliminates field polishing, while the splice-on design delivers low insertion loss for reflectance-sensitive applications. Compatible with leading fusion splicers and available in single mode OS2 and multimode OM2, OM3, and OM4.

Primus Cable provides LC fiber connectors manufactured to strict tolerances with competitive pricing. For questions, contact us at (951) 824-1571 or support@primuscable.com.
