Description

CAT3 Bulk Cable, UTP PVC Solid 24AWG, 25-Pair

Our CAT3 300 Volts Unshielded 25 pair CMR communications cable is perfect voice capabilities. Our Cat3 300Volts CMR Bulk Cable is ideal for telephone installation. Whether you are wiring your home, office or entire campus, our company has the solution thats right for you. This cable is designed for indoor type rated riser CMR installations.

Our CAT3 300 Volt riser CMR unshielded solid cable has 25 pairs of 24AWG solid bare copper conductors with a riser CMR rated PVC Jacket. Our Cat3 CMR solid unshielded cable is quality manufactured to meet and/or exceed product certifications and standards UL type CMR, C( UL)CMG, Passes UL 1666 Flame test, RoHS Compliant, TIA 568-B.2 Category 3 specifications. This cable is sold and shipped in 1000ft increments on a wooden Spool.

CAT3 Cable Options:

Solid Wire: also called solid-core or single-strand wire, consists of one piece of metal wire. Stranded wire is composed of a bundle of small-gauge wires to make a larger conductor and more flexible than solid wire. Solid wire is generally used for in-wall wiring where there is little need for flexibility in the wire.

CM/CMH/CMG: CM is used for general building wiring such as residential house. CM cables are used in areas other than plenums and risers.

CMR: The 'R' in CMR is for 'Riser'. Riser type cables are engineered to prevent the spread of fire from floor to floor and are suitable for vertical shaft applications.

CMP: The 'P' in CMP is for Plenum. Cables meeting type CMP requirements are suitable for installation in ducts and plenums without the use of conduit. These cables are designed for fire resistance and low-smoke and toxin producing characteristics.

Features

Features

High-Performance Voice Communications Cable
Designed for Indoor Installations, (CMR) Riser
25-Pair - Easily Identified Color-Striped Pairs
24AWG Solid Bare Copper Conductors
Insulation: Semi-rigid PVC
Jacket: Flame Retardent PVC
Passes UL 1666 Flame Test
RoHS Compliant
Supplied in Wooden Spools

Applications

Voice
10BaseT
100BaseVG
4Mbps Token Ring
10Mbps Ethernet
55Mps ATM
ISDN

Specifications

Physical Construction			Electrical Characteristics

	Conductor Material:	Solid Bare Copper		Operating Temperature	-10ºC to +75ºC
	Conductor Size	24 AWG		Voltage Rating	300 Volts
	Number of Conductors	50
	Number of Pairs	25
	Jacket Material:	Gray PVC
	Jacket Diameter:	0.343 inch
	Jacket Color:	Gray
	Insulation	nominal wall SR PVC

Color Pair Guide
Pair # - TIP
1 - White - Blue	18 - Yellow - Green	35 ---
2 - White - Orange	19 - Yellow - Brown	36 ---
3 - White - Green	20 - Yellow - Slate	37 ---
4 - White - Brown	21 - Violet - Blue	38 ---
5 - White - Slate	22 - Violet - Orange	39 ---
6 - Red - Blue	23 - Violet - Green	40 ---
7 - Red - Orange	24 - Violet - Brown	41 ---
8 - Red - Green	25 - Violet - Slate	42 ---
9 - Red - Brown	26 ---	43 ---
10 - Red - Slate	27 ---	44 ---
11 - Black - Blue	28 ---	45 ---
12 - Black - Orange	29 ---	46 ---
13 - Black - Green	30 ---	47 ---
14 - Black - Brown	31 ---	48 ---
15 - Black - Slate	32 ---	49 ---
16 - Yellow - Blue	33 ---	50 ---
17 - Yellow - Orange	34 ---	---

Additional Information

	Standards	UL \| CUL \| RoHS \| CMP
	Applications	10BaseT and 100BaseVG \| AnyLAN \| 4Mbps Token Ring \| 10Mbps Ethernet and 55Mps ATM
	Important Notes	The information contained in this document is proprietary to CRN Solutions and may not be disclosed or transmitted to any other parties without the express written permission of CRN Solutions. This information is provided for the purposes of quotation only.

Additional Information

Additional Information

To learn more about our Category 3 Bulk Cable here is a link to a page containing more information on our premium Category 3 Bulk Cable.

What's in the box?

What's in the box?

Qty 1 - CAT3 300 Volts CMR Unshielded Solid 25-Pair Cable supplied on a 1000ft spool
