Description

Schedule 40 Conduit, 10Ft Length

Our Schedule 40 PVC with a belled end, encases electrical cables and conductors, offering a smooth inside to facilitate easy wire pulling. Schedule 40 Conduit is corrosion resistant and can be used for direct burial applications including in concrete. This product is UL recognized, cost-effective and easy to install.

Product Quality

To ensure our Schedule 40 PVC Conduit provides you with the best protection available, our product is resistant to many ordinary chemicals such as acids, bases, salts, and oxidants. Schedule 40 PVC also serves as an insulation barrier against outside electrical interference from power lines. It has a high melt index and is engineered from self-extinguishing material so it prevents the spread of fires from faulty wiring.

Durability & Strength

Our Schedule 40 PVC Conduit is manufactured from high-grade PVC, providing a protective duct for cables and electrical conductors. This product is suitable for indoor or outdoor applications and can withstand direct sunlight exposure with its UV protection.

If you have any questions, feel free to give us a call or email us.

Features

Features

High Impact Protection
Coupling molded on one side
Pieces fuse together with PVC cement
Available in 1 1/2" to 4" Diameter
High strength for long service life
Lightweight and durable suitable for underground electrical applications
Non-Conductive, provides insulation against electrical interference
Holds strength regardless of water or soil conditions
Provides smooth, continuous raceways for fast wire-pulling
Quick and easy installation without the need for expensive equipment
Widely accepted by standard codes and regulations
Reusable

Specifications

Specifications

Size	Average O.D.	Nom. I.D.	Min. T.	Approx. Weight
3/4"	1.050	0.824	0.113	2.4
1"	1.315	1.049	0.113	3.3
1 1/4"	1.660	1.380	0.140	4.5
1 1/2"	1.900	1.610	0.145	5.6
2"	2.375	2.067	0.154	7.6
3"	3.5	3.068	0.216	16.3
4"	4.5	4.026	0.237	23.4

Additional Information

Conduit Accessories

Installing or retrofitting an electrical conduit system? We got you covered! We offer everything you need for a customized electrical conduit system including PVC pipe, conduit, and fittings. Our PVC pipe and fittings are engineered for commercial and residential power, lighting, telephone, and electrical systems.

What's in the box?

What's in the box?

Qty 1 - Schedule 40 PVC Conduit
