Miniature Overhead Door Floor Mount Magnetic Switch Set

This Overhead Door Contact Miniature Floor Mount Switch Set consists of a low profile reed switch made of cast aluminum for superior durability. Available in closed loop, open loop, open/closed SPDT, or DPDT configurations. It features a wide working gap of up to 2 1/2" with two feet (DPDT version comes with three feet) of heavy-duty armored cable.

The armored cable with this overhead door contact switch provides protection from the elements. The versatile universal magnet can be mounted at various angles for those difficult installations. A 1/4™ masonry bit is required for lead anchor installation.

Features

Features

Miniature floor mount
Available in closed loop, open loop, spdt or dpdt
24" armored cable (DPDT version comes with 36" cable)
Universal magnet for flexibility in mounting
Cast aluminum casings for harsh environments
Plated contacts resist sticking or freezing
Up to 2 1/2" gap for loose overheads
Reed switch for reliability
Mounting hardware included
Hermetically sealed
UL and ULC approved
Made in U.S.A.
Low cost

Specifications

Specifications

Technical Specs: Closed Loop

Loop Type:		Closed
Electrical Config:		N/O
Reed Form:		A
Maximum Intitial Contact Resistance (Ω):		.150
Maximum Contact Rating (W):		10
Maximum Switching Voltage (VDC):		200
Maximum Switching Current (A):		.500

Technical Specs: Open Loop

Loop Type:		Open
Electrical Config:		N/C
Reed Form:		B
Maximum Intitial Contact Resistance (Ω):		.140
Maximum Contact Rating (W):		5
Maximum Switching Voltage (VDC):		175
Maximum Switching Current (A):		.250

Technical Specs: Open/Closed SPDT

Loop Type:		Open/Closed
Electrical Config:		SPDT
Reed Form:		C
Maximum Intitial Contact Resistance (Ω):		.140
Maximum Contact Rating (W):		5
Maximum Switching Voltage (VDC):		175
Maximum Switching Current (A):		.250

Technical Specs: Open/Closed DPDT

Loop Type:
Electrical Config:		DPDT
Reed Form:		Cx2
Maximum Intitial Contact Resistance (Ω):		.140
Maximum Contact Rating (W):		5
Maximum Switching Voltage (VDC):		175
Maximum Switching Current (A):		.250

What's in the Box

What's in the Box

(1) - Miniature Overhead Door Floor Mount Switch Set
(1) - Two Feet of Armored Cable
(1) - Mounting Hardware
