Cable Ladder - 10' x 12" - Cable Ladder Rack System
by Primus Cable
Sold out
$188.95
SKU: NPNB-VLR-1210
Description
Our Cable Ladder Rack is an ideal solution anywhere an overhead cable run is required. The welded construction offers a maximum load of 132 lbs. per foot with minimum deflection (when supported every 5 ft). Constructed of (2)1-1/2 x 3/8 x 0.060 thick steel tubular stringers and (13) 1.00 x 1/2 cross members welded on 9.00 centers.
Features
Features
- Stringers: 1-1/2 x 3/8 x 0.06 thick tubular steel
- Cross Members: 1.00 x 1/2 thick tubular steel welded on 9.00 centers
- Offered in 10 foot long sections
- RoHS compliant
- Max. load w/min. deflection: 132 lbs. per ft if supported every 5 ft
- Packaged and sold individually
Specifications
Technical Illustration
| Product Type |
Cable Ladder Rack |
| Product Material (Stringers) |
1-1/2 x 3/8 x 0.06 Thick Tubular Steel |
|
Product Material (Cross Members) |
1.00 x 1/2 Thick Tubular Steel Welded on 9.00 Centers |
| Compliance & Standards | RoHS Compliant |
|
Max. Load W/ Min. Deflection |
132 lbs. Per Foot If Supported Every 5 Feet |
What's in the Box?
What's in the Box?
Qty 1 - 10 ft. Ladder Rack For Cable Runway
