100GBASE-CWDM4 QSFP Transceiver 2km SMF
This product is specifically designed to be fully compatible and functional with its brand's own designated switching devices. This QSFP28 optical transceiver is compliant with SFF-8665 and QSFP28 MSA standards. This module converts 4 input channels of 25Gb/s electrical data into 4 LAN-WDM optical signals and multiplexes them into a single channel for 100Gb/s optical transmission. On the receiver side, this module optically de-multiplexes a 100Gb/s input into 4 LAN-WDM channel signals and converts them to 4-channel output electrical data. This module is designed for single mode fiber using LC connection and operates at central wavelengths of 1271, 1291, 1311, 1331nm up to 2km over single mode fiber.
Features
Features
- Supports up to 100 GbE for high-speed data transfer
- Hot-pluggable QSFP28 footprint
- Equipped 1x LC Duplex UPC connector
- Built-in digital diagnostic function
- Features DOM support
- Operating C- temperature ranges from 0°C to 70°C
Specification
Specification
| Form Factor | QSFP28 |
| Max Data Rate | 100GbE |
| Wavelength | 1271nm, 1291nm, 1311nm, 1331nm |
| Max Cable Distance | 2KM over SMF |
| Connector | 1x LC Duplex UPC |
| DOM Support | YES |
| Power Supply | 0 |
| Operating Temperature Range | 0°Cto +70°C |
What's in the Box
What's in the Box
- Qty 1 – 100GBASE-CWDM4 QSFP Transceiver 2km SMF
