100GBASE-SR4 QSFP Transceiver MPO
This product is specifically designed to be fully compatible and functional with its brand's own designated switching devices. This QSFP optical transceiver is a parallel fiber optical module with four independent optical transmit and receive channels and is compliant with SFF-8665 and QSFP28 MSA standards. This module is designed for multimode fiber using MPO/MTP connection and operates at a nominal wavelength of 850m up to 70m over OM3 and 100m over OM4 fiber.
Features
Features
- Supports up to 100 GbE for high-speed data transfer
- Hot-pluggable QSFP28 footprint
- Equipped with 1x MPO-12 UPC connector
- Built-in digital diagnostic function
- Features DOM support
- Power supply rating: 0
- Operating C- temperature ranges from 0°C to 70°C
Specification
Specification
| Form Factor | QSFP28 |
| Max Data Rate | 100GbE |
| Wavelength | 850nm |
| Max Cable Distance | 100M over OM4 MMF, 70M over OM3 MMF |
| Connector | 1x MPO-12 UPC |
| DOM Support | YES |
| Power Supply | 0 |
| Operating Temperature Range | 0°Cto +70°C |
What's in the Box
What's in the Box
- Qty 1 – 100GBASE-SR4 QSFP Transceiver MPO
