5-Port 10/100Mbps Ethernet Switch with 4-Port PoE, Desktop
5-Port 10/100Mbps Ethernet Switch with 4-Port PoE, Desktop
BY TP-Link
SKU: SKU: TL-SF1005P
Couldn't load pickup availability
⚠ Various lead times may apply to this product. Please contact us for more details.
View full details
5-Port 10/100Mbps Ethernet Switch with 4-Port PoE, Desktop
The 5-Port 10/100Mbps desktop switch with 4-port PoE provides an easy way to expand your wired network. 4 of the 5 Auto-Negotiation RJ45 ports (Port 1 to Port 4) of the switch support Power over Ethernet (PoE) function. These PoE ports can automatically detect and supply power with those IEEE 802.3af compliant Powered Devices (PDs).
Intelligent Power Management
When total power consumption excels 58W, the intelligent power management will cut the lower priority port power off to ensure the high priority port’s power supply and protect the device from power overload operation..
Sturdy Metal Casing
Sturdy, compact metal casing and shielded RJ45 ports, with desktop/wall-mounting design, to meet your needs in any environment. Besides, fanless design ensures quiet operation.
Features
- 5 10/100Mbps RJ45 ports
- With four PoE ports, transfers data and power on one single cable
- Working with IEEE 802.3af compliant PDs, expands home and office network
- Supports PoE Power up to 15.4W for each PoE port
- Supports PoE Power up to 58W for all PoE ports
- No configuration and installation required
Specifications
| HARDWARE FEATURES | ||
|---|---|---|
| Interface | 5 x 10/100/1000 Mbps RJ45 Ports, Auto-Negotiation/Auto MDI/MDIX |
|
| Fan Quantity | Fanless | |
| Power Supply | External Power Adapter (Output: 53.5 VDC/ 1.31 A) |
|
| Dimensions (W x D x H) | 3.9 x 3.9 x 1.0 in (100 x 98 x 25 mm) |
|
| Max Power Consumption |
1.9 W (no PD connected) 74 W (with 67 W PD connected) |
|
| Max Heat Dissipation |
6.5 BTU/h(no PD connected) 252.3 BTU/h (with 67 W PD connected) |
|
| PERFORMANCE | ||
|---|---|---|
| Switching Capacity | 1 Gbps |
|
| Packet Forwarding Rate | 0.744 Mpps |
|
| MAC Address Table | 2 K |
|
| Jumbo Frame | 2 KB |
|
| GENERAL |
||
|---|---|---|
| Certification | FCC, CE, RoHS | |
| Package Contents |
TL-SF1005P Power Adapter Installation Guide |
|
| Environment |
Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
|
Ethernet Switch Accessories
An Ethernet network switch is a telecommunication device that receives data transmitted from a connected device and relays it to a specific device. Ethernet switches create separate collision domains per switch port, allowing for simultaneous data transfers to occur without interference. They also reduce the number of broadcast domains, and doesn't require heavy CPU usage. The Ethernet switch manages the flow of network traffic more efficiently and in a safer manner than repeater hubs. It allows for the flow of data between connected devices. Ethernet switches come in both managed and unmanaged varieties. Unmanaged switches are the easy to install, plug and play variety. To learn more about our Ethernet Switches please visit our overview page. Our Switches can be combined with a wide array of products such as:
What's In The Box
- (1) - 5-Port 10/100Mbps Desktop Switch with 4-Port PoE
- (1) - Power Adapter
- (1) - User Guide
