Description
5MP H.265 IP Mini PTZ Camera with 10x Optical Motorized Zoom Lens
This mini PTZ security camera uses a 1/2.7" CMOS sensor to capture 5MP resolution video at 20 fps. Featuring a 5-60mm motorized power zoom lens, a 355° horizontal rotation range, and a 90° vertical rotation range, this camera provides flexible coverage for a variety of security applications. It supports H.265/H.265+ video compression, PoE connectivity, 12VDC power, and mobile app control, while built-in infrared illumination provides visibility up to 98 feet in low-light conditions. With an IP67 weather-resistant and IK10 impact-resistant design, this NDAA-compliant mini PTZ camera is a reliable choice for indoor and outdoor security camera systems.
Features
Features
- 10x Optical Motorized Zoom Lens
- H.265 Compression
- 3.6” Explosion-Proof Housing with
- Quick-Install Design
- 90° Vertical, 355° Horizontal Pan / Tilt
- Built-in IR-Cut
- IR Up to 164 Feet
Specifications
| TECHNICAL SPECIFICATIONS | |
|---|---|
| IMAGE SENSOR | 1 / 2.7” CMOS |
| RESOLUTION | 5MP 2592 (H) x 1944 (W) |
| MIN. ILLUMINATION | Color 0.05lux @ F1.2 (AGC ON) |
| SIGNAL-TO-NOISE RATIO | 50dB |
| POWER ZOOM (MM) | 4.7 - 47mm |
| VERTICAL ROTATION | 90° |
| HORIZONTAL ROTATION | 355° |
| INFRARED LIGHT | Double Array Lamp |
| INFRARED DISTANCE | Up to 164 Feet |
| DAY/NIGHT MODE | Auto / Day / Night |
| BACKLIGHT MODE | Close / Open |
| COLOR DENSITY | Adjustable via Menu |
| CONTRAST | Adjustable via Menu |
| DIGITAL NOISE REDUCTION | 3D Digital Noise Reduction |
| WHITE BALANCE | Manual / Automatic White Balance |
| ELECTRONIC SHUTTER | Auto, 1/25s – 1/10,000s |
| PRESET POSITIONS | 48 |
| WATCH POINT | 1 |
| APP CONTROL | Supports Mobile App Control |
| ETHERNET | RJ-45 (10/100BASE-T) |
| VIDEO COMPRESSION | H.265 / MJPEG |
| VIDEO TRANSMISSION RATE | Variable / Constant (128Kbps~12Mbps Second) |
| FRAME RATE / RESOLUTION | 5MP @ 20FPS |
| BIT STREAM | Double Stream |
| PROTOCOL | ONVIF 2.4 |
| OPERATING TEMP. AND HUMIDITY | -40°F ~ 131°F < 90% RH |
| STORAGE TEMP. AND HUMIDITY | -22°F ~ 140°F < 90% RH |
| WEATHER RATING | IP66 |
| INPUT VOLTAGE | 12VDC±10% |
| POWER CONSUMPTION | 800mA / 3.1W (Peak 1A/8W) |
| PHYSICAL CHARACTERISTICS | |
| COLOR / MATERIAL | White / Metal |
| LENS COVER | High Intensity Gray - Black High Transparency Plexiglass |
| CONNECTION PORT | RJ-45 Port / 12VDC Plug |
| DIMENSION | 4.73 in (W) x 4.49 in (H) |
| WEIGHT | 1.41 lbs |
What's In The Box
What's In The Box
- Qty 1 - 5MP H.265 IP Mini PTZ Camera with 10x Optical Motorized Zoom Lens
