This product is intended to be purchased by installers only
Features
- Support 4 or 6 channels of additional HDMI outputs
- For use in video walls
- Supports NR6416 & NR12816 network recorders only
- HDMI resolution up to 4K, 3840 x 2160
- H.265 & H.264 standards support
Specifications
| VIDEO TEST MONITOR | |
|---|---|
| HDMI Port | Supports 4 or 6 ch |
| HDMI Output 4-ch |
Ports HDMI1 & HDMI3: 1920×1080p/60Hz, 1920×1080p/50Hz 1600×1200/60Hz, 1280×1024/60Hz 1280×720/60Hz, 1024×768/60Hz Ports HDMI2 & HDMI4: 4K (3840×2160)/60Hz, 4K (3840×2160)/30Hz 1920×1080p/60Hz, 1920×1080p/50Hz 1600×1200/60Hz, 1280×1024/60Hz 1280×720/60Hz, 1024×768/60Hz |
| HDMI Output 6-ch |
Ports HDMI1, HDMI2 & HDMI4: 1920×1080p/60Hz, 1920×1080p/50Hz 1600×1200/60Hz, 1280×1024/60Hz 1280×720/60Hz, 1024×768/60Hz Ports HDMI3, HDMI5 & HDMI6: 4K (3840×2160)/60Hz, 4K (3840×2160)/30Hz 1920×1080p/60Hz, 1920×1080p/50Hz 1600×1200/60Hz, 1280×1024/60Hz 1280×720/60Hz, 1024×768/60Hz |
| Camera Capability (fps): 4-ch |
8×4K@30, 16×4MP@30 32×1080P@30, 64×720P |
| Camera Capability (fps): 6-ch |
12×4K@30, 24×4MP@30 48×1080P@30, 96×720P |
| Multi-window | 1/3/4/5/6/7/8/9/16 |
| Working Humidity | 10%~90% |
| Weight | 1kg (2.2lb) |
