This product is intended to be purchased by installers only
Description
Description
The Mini SAS 8 Bay HDD Disk Enclosure offers high-density storage with support for up to eight hot-swappable 3.5” SATA or SAS drives, delivering up to 32TB capacity. Designed for high performance and reliability, it features mini-SAS interface for fast data transfer, efficient cooling, and rack-mount installation, ideal for video surveillance and server storage expansion.
Features
Features
- High density disk enclosure
- Supports NR6416, NR12816 and NR25616 Uniview Tec model network recorders
- High performance and reliability developed specifically for video surveillance
- Supports 8 SATA HDDs, up to 10TB each for a total of 80TB
- Standard rack mount installation
- Power sequentially managed during startup, with protection from impulse current
- Multi-stage fans provide heat dissipation to ensure low power consumption and stable operation
- Space saving, 2U height
Specifications
Specifications
| Storage | ||
|---|---|---|
| Hard Disk Drives | 8 x SATA HDD's | |
| Capacity | Up to 10TB each | |
| General | ||
| Expansion Interface | 1 x Mini-SAS | |
| Power | 100-240VAC | |
| Consumption | 100W maximum, w/o HDD's | |
| Operating Temperature | -10°C ~ +55°C (+14°F ~ +131°F) Humidity ≤90% RH (non-condensing) | |
| Dimensions (W × D × H) | 442 × 530.4 × 86.1 mm (17.4 × 20.88 × 3.39") | |
| Weight (w/o HDD) | 8kg (17.6lb) | |
What's in the Box
What’s in the Box
- Qty 1 - Mini SAS 8 Bay HDD Disk Enclosure
- Qty 8 - Removable HDD Tray Modules
- Qty 1 - Power Cord
- Qty 2 - Mini-SAS HD Cables
- Qty 1 - Quick Installation Manual & CD
- Qty 1 - Set of Screws or Mounting Hardware
