Standard Surface Mount Switch Sets - 29P Series - 10 Pack

by GRI
$64.20
SKU: 29PA-12
Size & Diameter
Gap
Loop Type
Various lead times may apply to this product. Please contact us for more details.

These products are all Made to Order

Which means they are non-cancelable and non-refundable

Description

Standard Surface Mount Switch Sets - 29P Series - 10 Pack

The 2 conductor jacketed lead style surface mount switch sets are applicable for both residential and commercial installations. This versatile series sets the industry standard for commercial and light industrial applications. They can be installed on a steel surface with a minimum gap penalty. You can choose between multiple cable lengths and the following gap sizes: Up to 1" (5/8" On Steel) standard, up to 1 1/2" (3/4" On Steel) wide or up to 2" (1" On Steel) extra wide gap.

Features

  • Lifetime warranty against workmanship, material and factory defects
  • UL and ULC approved
  • Concealed terminals on 28 Series
  • 24" jacketed cable on PA Series
  • Longer leads upon request on PA series
  • Side mounted screw terminals on 29 series
  • Standard gap up to 1", 5/8" on steel
  • Wide gap up to 1 1/2", 3/4" on steel
  • Extra wide gap up to 2", 1" on steel
  • Spacers, covers and screws Included
  • Private labeling on request
  • Built-in E.O.L. resistors and diodes available on request
  • Switches or magnet only are available separately
  • Supervisory loop or dummy terminals available
  • Made In U.S.A.

Specifications


What's In The Box

  • 10 x Surface Mount Magnetic Reed Switches
  • 10 x Magnets
  • Mounting Hardware
