This item is final sale and is not eligible for return, exchange, refund, or order cancellation. Please review product details carefully.
Former Part Number: CN1-008-6CUL
Description
RJ12 Plug, 6 Position, 6 Conductor, For CAT3 Round Solid or Stranded Wire.
Primus Cables RJ12 telephone plugs are made with high standards, keeping our customers and their phone systems in mind. Even with something as small as an RJ12 plug, it must be made right and it must work right. These RJ12s work with stranded and solid cables with 6 positions and 6 conductors (gold plated).
Specifications
| TECHNICAL SPECIFICATIONS | |
|---|---|
| HOUSING | POLYCARBONATE, UL94V-0 |
| COLOR | TRANSPARENT |
| CONTACT BLADE | PHOSPHOR AND BRONZE |
| CONDUCTOR | STRANDED & SOLID WIRE 24, 26 & 28 AWG (FOR WIRE OD 0.96–1.02MM) |
| GOLD PLATING | 50µ |
| UL APPLICATIONS | 250 VOLTS AC MAX., AT 2 AMPS |
| DIELECTRIC WITHSTANDING VOLTAGE | 500 VOLTS AC |
| INSULATION RESISTANCE | 100 MΩ |
| TERMINATION RESISTANCE | 20MΩ MAX AFTER ENVIRONMENTAL TESTING |
| CABLE‑TO‑PLUG TENSILE STRENGTH | 20 POUND MIN. |
| DURABILITY | 350 MATTING CYCLES |
Additional Information
To learn more about our Telephone Jacks here is a link to a page containing more information on our premium Telephone Jacks.
What's In The Box
What's In The Box
CN1-7873-6CUL:
- Qty 1 (25 Pack) - RJ12 Connector
