Slim Fiber Connector Cleaner, MPO 12 Core
The Jonard Tools FCCS-120 Slim Fiber Connector Cleaner is designed to provide exceptional cleaning performance for MPO and MTP 8, 12 & 12x2 (24) core fiber connectors. Ideal for use in data centers, telecom rooms, fiber panels, and other high-density fiber environments, this compact cleaner uses ultra-fine microfiber to remove dust, oil, and debris without scratching or damaging the connector endface. Perfect for both plug and port cleaning, especially in tight or hard-to-reach areas.
Jonard cleaners meet or exceed all current and emerging standards for fiber cleanliness in high power laser applications (IEC 61300-3-35). Limited Warranty
Fiber Optic Cleaning
Mitigate the risk of fiber optic contamination with fiber optic cleaners, fiber cleaning pens, and cleaning wipes. These handy fiber cleaners can remove contaminants like: dust, dirt, oils, film residue, and solvent coating.
Airborne dirt particles are about the size of the core of SM fiber and are usually silica-based - they may scratch PC connectors if not removed! Patch panels have mating adapters that can become contaminated if left open to the air or scrape off foreign particles under repeated usage. We recommend you always keep dust caps on connectors, bulkhead splices, patch panels, or anything else that is going to have a connection made with it.
Features
Features
- Effectively cleans MPO and MTP 8, 12 & 12x2 (24) core fiber connectors, including flat and 8° angled types, with (female) or without (male) guide pins.
- One-push operation provides quick and consistent cleaning with minimal effort.
- Compact, slim design allows easy access in tight spaces and includes a strap for secure handling and drop prevention.
- Built-in adapter cap allows easy switching between plug and port cleaning.
- Transparent housing to monitor remaining tape; color-coded label for connector identification.
- ESD-safe housing and cleaning cloth provides more than 700 swipes per cleaner.
Specifications
| TECHNICAL SPECIFICATIONS | |
|---|---|
| FIBER TYPE/APPLICATION | MULTI-FIBER, SIMPLEX |
| CONNECTOR TYPE | MPO, MTP CONNECTORS: 8, 12, 24 (12X2) |
| POLISH TYPE | PC, UPC, APC |
| PIN CONFIGURATION | MALE (WITH PINS) OR FEMALE (NO PINS) |
| NUMBER OF CLEANS | 600+ |
| CLEANING MOTION | 180°, PUSH FORWARD |
| GUIDE TYPE | STANDARD |
| CLEANING DEPTH | 3.525” (89.54 MM) |
| STANDARDS | IEC 61300-3-35 |
| CLEANING FABRIC | STATIC-FREE MICRO FIBER |
| DIMENSIONS | 8 IN X 2 IN X 0 IN (20.32 CM X 5.08 CM X 0 CM) |
| WEIGHT | 0.1 LB (45.4 G) |
| UPC # | 810132439254 |
Additional Information
| Product Videos | |
|---|---|
FCCS-120 MPO 12 SLIM FIBER CONNECTOR CLEANER |
What's in the Box
What's in the Box
- Qty 1 – Slim Fiber Connector Cleaner, MPO 12 Core
