This product is intended to be purchased by installers only
Description
The 4MP ColorHunter Wise-ISP Turret is an NDAA‑compliant IP camera designed to deliver full‑color images around the clock, even in very low light, making it ideal for entrances, parking areas, and general surveillance where color detail matters. Its 1/1.8" CMOS sensor, 2.8mm fixed wide‑angle lens, 120 dB WDR, and warm‑light illumination provide clear, balanced video in challenging lighting, while H.265 compression helps reduce bandwidth and storage requirements. With built‑in microphone, smart intrusion analytics focused on humans and vehicles, edge storage up to 512GB with ANR, and an IK10/IP67 metal housing, this turret offers a rugged, high‑performance option for commercial deployments.
Features
Features
Key Features
- Fully Adheres to National Defense Authorization Act (NDAA) Guidelines
- Color Hunter with Wise-ISP technology ensures 24-hour full-color images
- High quality image with 4 MP, 2560×1440 Resolution
- Super-Efficient H.265 Video Compression for Drastically Reduced Bandwidth and Storage Requirements
- White Light, up to 30 m (98.4 ft.) IR distance
- 2.8mm Fixed Lens; ONVIF Profile S Compliant
- Dual Video Streams, Built-In Mic, Digital Defog and 3D DNR
- Intelligent, smart intrusion prevention technology for significantly reduced false alarms when focusing on humans and motor vehicles
- POE & 12VDC Power options and Optional Wall and Pendant Mounts available
- Built-in Micro-SD Card Slot enables local storage up to 512GB and ANR
- 3-Way Axis, IP67 Weather Resistant and IK10 Vandal Resistant Rated Housing
- Supported by uniview tec Guard Station Software, as well as Guard Live and Guard Viewer Mobile App’s for iPhone and Android Devices
Specifications
| Camera | ||||||
|---|---|---|---|---|---|---|
| Sensor | 1/1.8" CMOS | |||||
| Minimum Illumination | Color: 0.0003 Lux (F1.0, AGC ON) | |||||
| True Day / Night | Wise-ISP | |||||
| Smart Illumination | Support | |||||
| Shutter | Auto / Manual, 1 ~ 1/100000s | |||||
| WDR | 120 dB | |||||
| S/N | >52dB | |||||
| Lens | ||||||
| Lens | 2.8 mm | |||||
| Iris | F1.0 | |||||
| Field of View (H) | 124.3° | |||||
| Field of View (V) | 61.4° | |||||
| Field of View (D) | 135° | |||||
| DORI | ||||||
| DORI Distance |
|
|||||
| Illuminator | ||||||
| IR Range | N/A | |||||
| Warm Light Range | 30 m (98.4 ft.) | |||||
| Wavelength | ~3000 nm | |||||
| Supplemental Light | N/A | |||||
| Video | ||||||
| Video Compression | H.265, H.264, MJPEG | |||||
| Frame Rate | 4 MP (2688 × 1520), max. 25 fps (Main Stream) 4 MP (2560 × 1440), max. 25 fps (Main Stream) 3 MP (2304 × 1296), max. 30 fps (Main Stream) 1080P (1920 × 1080), max. 30 fps (Main Stream) 720P (1280 × 720), max. 30 fps (Main Stream, Sub Stream) D1 (720 × 576), max. 30 fps (Sub Stream) 640 × 360, max. 30 fps (Sub Stream) 2CIF (704 × 288), max. 30 fps (Sub Stream) CIF (352 × 288), max. 30 fps (Sub Stream) |
|||||
| Video Bit Rate | 128 Kbps~ 16 Mbps | |||||
| ROI | Support | |||||
| OSD | Up to 4 | |||||
| Privacy Mask | Up to 4 areas | |||||
| Video Stream | Dual streams | |||||
| Image | ||||||
| White Balance | Auto / Outdoor / Fine Tune / Sodium Lamp / Locked / Auto2 | |||||
| Digital Noise Reduction | 2D/3D DNR | |||||
| Flip | Normal / Vertical / Horizontal / 180° / 90° Clockwise / 90° Anti-clockwise | |||||
| HLC | Support | |||||
| BLC | Support | |||||
| Defog | Digital Defog | |||||
| Dewarping | N/A | |||||
| Events | ||||||
| Basic Detection | Motion detection, Ultra motion detection, Tampering alarm, Audio detection | |||||
| Smart Detection | Intrusion, crossline detection (both detection are based on human body and vehicle detection) | |||||
| General Function | Watermark, IP Address Filtering, Access Policy, ARP Protection, RTSP Authentication, User Authentication, HTTP Authentication | |||||
| Other Function | N/A | |||||
| Audio | ||||||
| Audio Compression | G.711U, G.711A | |||||
| Audio Bitrate | 64 Kbps | |||||
| Two-way Audio | N/A | |||||
| Suppression | Support | |||||
| Sampling Rate | 8KHZ | |||||
| Storage | ||||||
| Edge Storage | Micro SD, up to 512GB | |||||
| Network Storage | ANR; NAS (NFS) | |||||
| Network | ||||||
| Protocols | IPv4, IPv6, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTSP, DNS, DDNS, NTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, SSL/TLS | |||||
| Compatible Integration | ONVIF (Profile S, Profile G, Profile T), API, SDK | |||||
| User/Host | Up to 32 users. 3 user levels: administrator and common user | |||||
| Client | Guard Station, Guard Viewer, Guard Live | |||||
| Web Browser | Plug-in required live view: IE 10+, Chrome 45+, Firefox 52+, Edge 79+; Plug-in free live view: Chrome 57+, Firefox 58+, Edge 16+ | |||||
| Pan & Tilt (N/A) | ||||||
| Optical Zoom | N/A | |||||
| Pan | N/A | |||||
| Tilt | N/A | |||||
| Presets | N/A | |||||
| Patrols | N/A | |||||
| Dwell Times | N/A | |||||
| Home Position | N/A | |||||
| Auto Tracking | N/A | |||||
| Interface | ||||||
| Audio I/O | 0/0 | |||||
| Alarm I / O | 0/0 | |||||
| Built-in Mic | Support | |||||
| Built-In Speaker | N/A | |||||
| Network | 1 x RJ45 10M/100M Base-TX Ethernet | |||||
| Additional Ports | N/A | |||||
| General | ||||||
| Power | DC 12 V±25%, PoE (IEEE 802.3af) Max. 4.0 W; Ø5.5 mm coaxial power plug | |||||
| Dimensions & Weight | Ø128 mm × 100 mm (Ø5.0" × 3.9") (Ø × H); 0.61 kg (1.34 lb.) | |||||
| Material | Metal | |||||
| Environment | Working: -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) Storage: -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
|||||
| Screws & Offset | 3- Ø3.8mm; Ø 108.5mm | |||||
| Reset Button | Support | |||||
| Conformity Certifications | IP67, IK10, CE, UL, FCC | |||||
What's in the Box
What's in the Box
- Qty 1 – 4MP ColorHunter Wise-ISP Turret Camera (Model IPV4WI28X)
