Uniview Tec - 8MP HD Intelligent Light and Audible Fixed Eyeball Network Camera

Uniview Tec - 8MP HD Intelligent Light and Audible Fixed Eyeball Network Camera

BY Uniview

$669.00 USD
$669.00 USD
Sale Sold out

SKU: IPB4KD28AIX

 ⚠ Various lead times may apply to this product. Please contact us for more details.

View full details

IP67 Rated

UL Listed logo

This product is intended to be purchased by installers only

Description


The 8MP HD Intelligent Light and Audible Fixed Eyeball Network Camera is an NDAA‑compliant Color Hunter device that delivers full‑color images around the clock, even in low‑light environments where traditional IR cameras would switch to black and white. Its 1/2.7″ 8MP CMOS sensor, 2.8mm fixed lens, 130 dB true WDR, and dual intelligent warm/IR deterrence lighting provide clear, balanced video and active visual warnings in challenging scenes. With built‑in microphone and speaker for true two‑way audio, smart intrusion analytics with human and vehicle classification, on‑board microSD storage up to 512GB with ANR, and an IP67 metal housing, this eyeball camera is well‑suited for professional perimeter, storefront, and small commercial deployments.

Features

Features

Key Features

  • Fully Adheres to National Defense Authorization Act (NDAA) Guidelines
    • Color Hunter with Wise-ISP technology ensures 24-hour full-color images
    • High quality image with 8 MP, 1/2.7″ CMOS sensor; Ultra 265, H.265, H.264, MJPEG
    • Smart Intrusion prevention, support false alarm filtering, Cross Line Detection, Intrusion Detection
    • 130 dB true WDR technology ensures clear image in strong backlight scene
    • Two-way Audio, Built in Mic and Speaker
    • Smart IR, up to 40 m (131.2ft) IR distance
    • DC12V or PoE (IEEE 802.3af) power supply
    • Built-in Micro-SD Card Slot enables local storage up to 512GB and ANR
    • IP67 Weather Resistant Housing and Optional Mounts Available

    Specifications


    Camera
    Sensor 1/2.7" CMOS
    Minimum Illumination Color: 0.002 Lux (F1.4, AGC ON), 0 Lux with light
    True Day / Night IR-cut filter with auto switch (ICR)
    Smart Illumination Support
    Shutter Auto / Manual, 1 ~ 1/100000s
    WDR 130dB
    S/N >56dB
    Lens
    Lens 2.8 mm
    Iris F1.4
    Field of View (H) 98.7°
    Field of View (V) 53.6°
    Field of View (O) 113.4°
    DORI
    DORI Distance

    Lens (mm)

    2.8 mm

    Detect(m)

    84.0 m (275.6 ft.)

    Observe(m)

    33.6 m (110.2 ft.)

    Recognize(m)

    16.8 m (55.1 ft.)

    Identify(m)

    8.4 m (27.6 ft.)
    Illuminator
    IR Range 40 m (131.2 ft.)
    Warm Light Range 40 m (131.2 ft.)
    Wavelength 850nm
    Supplemental Light Dual light with Red and Blue Deterrence Lights
    Video
    Video Compression H.265, H.264, MJPEG
    Frame Rate

    8 MP (3840 × 2160), max. 30 fps (Main Stream)

    5 MP (3072 × 1728), max. 30 fps (Main Stream)

    4 MP (2560 × 1440), max. 30 fps (Main Stream)

    1080P (1920 × 1080), max. 30 fps (Main Stream, Sub Stream)

    720P (1280 × 720), max. 30 fps (Main Stream, Sub Stream)

    D1 (720 × 576), max. 30 fps (Sub Stream, Third Stream)

    640 × 360, max. 30 fps (Sub Stream, Third Stream)

    2CIF (704 × 288), max. 30 fps (Third Stream)

    CIF (352 × 288), max. 30 fps (Third Stream)
    Video Bit Rate 128 Kbps~ 16 Mbps
    ROI Support
    OSD Up to 8
    Privacy Mask Up to 4 areas
    Video Stream Support
    Video Stream Triple streams
    White Balance Auto / Outdoor / Fine Tune / Sodium Lamp / Locked / Auto2
    Digital Noise Reduction 2D/3D DNR
    Flip Normal / Vertical / Horizontal / 180° / 90° Clockwise / 90° Anti-clockwise
    HLC Support
    BLC Support
    Defog Digital Defog
    Dewarping N/A
    Events
    Basic Detection Motion detection, Ultra motion detection, Tampering alarm, Audio detection
    Smart Detection Cross line detection, intrusion detection, enter area detection, leave area detection (support false alarm filtering and the classification of human, non-motor vehicle and vehicle); People flow counting and crowd density monitoring
    General Function Watermark, IP Address Filtering, Alarm input, Access Policy, ARP Protection, RTSP Authentication, User Authentication
    Other Function N/A
    Audio
    Audio Compression G.711U, G.711A
    Audio Bitrate 64 Kbps
    Two-way Audio Support
    Suppression Support
    Sampling Rate 8KHZ
    Storage
    Edge Storage Micro SD, up to 512GB
    Network Storage ANR; NAS (NFS)
    Network
    Protocols IPv4, IPv6, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, UPnP, HTTP, 802.1x, SNMP, QoS, SSL/TLS, SSH, HTTPS, SMTP
    Compatible Integration ONVIF (Profile S, Profile G, Profile T), API, SDK
    User/Host Up to 32 users. 3 user levels: administrator, common user and operator
    Client Guard Station, Guard Viewer, Guard Live
    Web Browser Plug-in required live view: IE 10+, Chrome 45+, Firefox 52+, Edge 79+; Plug-in free live view: Chrome 57+, Firefox 58+, Edge 16+
    Pan & Tilt (N/A)
    Optical Zoom N/A
    Pan N/A
    Tilt N/A
    Presets N/A
    Patrols N/A
    Dwell Times N/A
    Home Position N/A
    Auto Tracking N/A
    Interface
    Audio I/O 0/0
    Alarm I / O 0/0
    Built-in Mic Support
    Built-In Speaker Support
    Network 1 x RJ45 10M/100M Base-TX Ethernet
    Additional Ports N/A
    General
    Power DC 12V (±25%) on Ø5.5 mm coaxial power plug, PoE+ (IEEE 802.3af); Max. 11.5W; 4 KV Surge
    Dimensions (L × W × H) 192 mm × 75 mm × 74 mm (7.6" × 3.0" × 2.9")
    Material Metal
    Environment Working: -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
    Storage: -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
    Screws & Offset 3- Ø4.5mm; Ø 98.0mm
    Reset Button N/A
    Conformity Certifications IP67, CE, UL

    Additional Information


    •  TR-SM05-IN, Fixed Dome Switch Box Adapter – View Product

    What's in the Box

    What's in the Box

    • Qty 1 – IPB4KD28AIX 8MP HD Intelligent Light and Audible Fixed Eyeball Network Camera
