Description
APPLICATIONS
- Used as primary insulation for wire and cable splices up to 600 volts
- Used for wire harnessing
- Used for jacketing on high voltage splices
Features
- Superior adhesion and elasticity
- Extreme weather performance
- Excellent tensile strength
- Highly resistant to UV, abrasion, and corrosion
- Flame-retardant
Specifications
- Thickness: .007”
- Width: ¾”
- Length: 66’
- Backing: Plasticized polyvinylchloride (PVC)
- Adhesive material: rubber-based
- Thickness 7 mil
- Adhesion to steel 33.3 oz/in
- Adhesion to backing 33.2 oz/in
- Tensile strength 19.8 lb/in
- Elongation 285.9%
- Operating temperature 0°F - 221°F
- Dielectric strength 1289.61 V/mil
- Certification UL/CSA
Additional Features
STORAGE CONDITIONS
Product should be stored in humidity-controlled, dry conditions between 50°F and 73°F (10°C and 23°C). Relative humidity should be less than 65%.
APPLICABLE REGULATORY STANDARDS
- UL Listed; UL Standard 510
- CSA Certified; CSA Standard C22.2
