Mini-SAS, 8-Bay HDD, Disk Enclosure

SKU: NASDE08

High density disk enclosure
Supports NR6416, NR12816 and NR25616 Uniview Tec model network recorders
High performance and reliability developed specifically for video surveillance
Supports 8 SATA HDDs, up to 10TB each for a total of 80TB
Standard rack mount installation
Power sequentially managed during startup, with protection from impulse current
Multi-stage fans provide heat dissipation to ensure low power consumption and stable operation
Space saving, 2U height

Storage
Hard Disk Drives	8 x SATA HDD's
Capacity	Up to 10TB each
General
Expansion Interface	1 x Mini-SAS
Power	100-240VAC
Consumption	100W maximum, w/o HDD's
Operating Temperature	-10°C ~ +55°C (+14°F ~ +131°F) Humidity ≤90% RH (non-condensing)
Dimensions (W × D × H)	442 × 530.4 × 86.1 mm (17.4 × 20.88 × 3.39")
Weight (w/o HDD)	8kg (17.6lb)
