2 Strand Fiber, SM, 9/125, PE Jacket, Flat Drop, Dry Loose Tube, Gel-Free,Water Block, Toneable, Black (Sold Per Foot)

(We do not offer credits or returns for this item.)

This fiber cable is priced per foot.

Note: Orders over 1200ft must ship freight and requires a shipping quote. To request a shipping quote email us or call us

If you would like to inquire about our custom fiber cable options such as terminated ends, or pulleyes please call or email us.

Description

Flat Drop Cable Gel-Free Single Mode Fiber, Polyethylene Jacket

This 2-strand single-mode fiber optic cable is designed for reliable and durable outdoor applications. It features a 9/125 µm core and a robust PE jacket for enhanced protection against environmental elements. The flat drop construction ensures easy handling and installation, while the gel-free, dry loose tube design minimizes mess and simplifies preparation.

Equipped with water-blocking technology, this cable is built to withstand moisture and harsh weather conditions, making it ideal for outdoor installations.

Features

Features

• Ease of handling and excellent tensile strength, ideal for outdoor deployments
• Singlemode, 9/125 SM
• Black PE jacket offers robust protection
• Gel-free design
• Water-block technology
• FRP (Fiber Reinforced Plastic) strength member with a diameter of 1.5mm

Specifications

Specifications

Spec Sheet

• Cladding Diameter: 125.0+/-0.7μm
• Cladding Non-Circularity: ≤1.0%
• Core-Clad Concentricity Error: ≤0.6μm
• Coating Diameter: 242+/-7μm
• Coating-Cladding Concentricity error:≤12 μm
• Cable Cutoff Wavelength: ≤1260 nm
• Attenuation (Maximum):
  ≤ 0.35 dB/km @1310nm
  ≤ 0.21 dB/km @1550nm
