Cam-Box™ Kit for Installing a Security Camera
Introducing our CAM-LIGHT™ Box, designed for hassle-free installation of fixtures, smoke detectors, and more on suspended or drywall ceilings, as well as walls. Tested to hold up to 50lbs on suspended or drywall ceilings, it saves both time and money. This versatile product accommodates any security camera hole pattern as you drill holes in the mounting plate. Larger cameras (with a 4.5" to 7" diameter base) can be mounted directly to the box flange. The CAM-LIGHT BOX features a drop wire for support, mounting wings for ceiling attachment, and 1/2" and 3/4" knockouts for easy installation.
Features
Features
- Designed to install security cameras to a suspended ceiling panel - fast with a 4" hole saw
- Rated up to 50 lbs on a suspended ceiling (or drywall ceiling) in combination with the drop wire for support
- Rated up to 10 lbs on a drywall ceiling without drop wire
- Rated up to 7 lbs on walls
- For security cameras, it fits any hole pattern because you drill the holes in the appropriate location in the flange, cameras with mounting holes set wider than 4.5" apart install directly to the box flange
- Mounting wings hold bracket securely against wall when screws are tightened
- White, non-metallic, paintable flange
- Steel version for use where metal raceways are required
- Steel version installs with 4-1/2" hole saw
- 1/2" and 3/4" knockouts
- Box rotates in either direction for proper camera position
Specifications
Specifications
| PHYSICAL INFORMATION | |
| Weight | 1.200 lbs/each |
| Height | 7.345" |
| Width | 7.345" |
| Color | White |
| Material(s) | Steel (Box) |
| Paintable | Yes |
| TECHNICAL INFORMATION | |
| Cubic Inches | 17.0 |
| Knockout Size(s) | 1/2" and 3/4" |
| Trade Size | 17.0 cu. in. |
Additional Information
Additional Information
What's In The Box
What's In the Box
- Qty 1 - Cam-Box™ Kit for Installing a Security Camera
